Oxford MIDI Floor Hoist

Oxford MIDI Floor Hoist

VERSATILE WITH OUTSTANDING PERFORMANCE

The Oxford® Midi 180 has become the ‘gold standard’ in home care, offering surprising performance for a hoist of its size. The Midi is the perfect solution for both community and nursing environments, whilst being sympathetic to the space constraints it might encounter.



  • Smart Monitor diagnostic and service controls as standard
  • Electric leg spread
  • High-grade Tente® castors for easy manoeuvrability
  • Choice of three spreader bar sizes
  • Detachable battery pack and desktop charger
  • Optional Class III digital weigh-scale.



Safe Working Load: 180Kg

Product Codes: Oxford Midi Electric Leg Lift (HF2029), Oxford Midi Hydraulic Lift (HF3339), Oxford Midi Electric Lift (HF3341)

Oxford MIDI Floor Hoist
  • Interchangeable Spreader Bars: Available in three sizes, small, standard and large to accommodate a wider variety of patient shapes and sizes.
  • Emergency Descent: Manually operated emergency descent function for increased patient safety.
  • Over-sized Push Handle: Optimised position and ergonomically designed for ease of manoeuvrability.
  • Electric Leg: Available with electrically powered legs ensuring effortless opening and closing of the legs.
  • High Grade Tente® Castors: A highly durable design that aids manoeuvrability over the majority of floor surfaces. The rear castors incorporate an easy to operate brake pedal (as shown)
  • Optional Foot Pedal Leg Adjustment:  The ergonomically designed foot pedal is perfectly positioned to ensure the user’s foot remains level during operation, helping to avoid risk of injury.
  • Available in electric and hydraulic versions. Electrically operated leg open/close models also available.
  • Standards Compliance: AS/NZS ISO 10535:2011, Hoists for the transfer of disabled persons

Specifications

Safe working load

180kg

SmartTM Monitor diagnostic and service controls as standard Length

1225 mm

Maximum Overall Height

1840 mm

Minimum Overall Height

1240 mm

Maximum Spreader Bar Height

1660 mm

Minimum Spreader Bar Height

525 mm

Spreader Bar Height at Maximum Reach:

1060 mm

Spreader Bar Reach at Maximum Height:

420 mm

Spreader Bar Reach at Minimum Height:

440 mm

Maximum Reach:

656 mm

Turning radius

1235 mm

Legs Open - External Width

1170 mm

Legs Open - Internal Width

1070 mm

Legs Closed - External Width

600 mm

Legs Closed - Internal Width

540 mm

Overall Height of Legs

100 mm

Ground Clearance

25 mm

Front Twin Castors

75 mm

Rear Braked Castors

100 mm

Mast and Boom Assembly

20.5 kg

Base Assembly

11.5 kg

Total Weight

32 kg









Electrical Specifications








Battery




1 x 24-volt rechargeable sealed lead acid type








Battery capacity




2.9 Ampere hours








Charger rated input




100 - 240 V AC / 50 / 60 Hz








Charger rated output




29.5 V DC Max 19W / IPX5














For options & accessories, please contact our Product Specialists.





















    Available Downloads:





















  Oxford Midi 180 Brochure






















  Oxford Midi 180 User Manual
